| Place of Origin: | Shanxi |
| Brand Name: | GY LED Lighting |
| Certification: | CE ,ROHS ,ISO |
| Model Number: | GY290FG |
| Minimum Order Quantity: | 10pcs |
|---|---|
| Price: | Negotation |
| Packaging Details: | Carton |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, T/T, Western Union/Paypal |
| Supply Ability: | 300000pcs/Year |
| Power: | 18W/25W/30W | IP: | IP65 |
|---|---|---|---|
| CRI: | Ra≥70 | Power Factor: | PF ≥0.9 |
| Input Voltage: | AC220 ～ 240V | Color Temperature: | 3000/4000/5000/5700K |
| Electrical Insulation Class: | CLASS I | Warranty: | 5 Years |
| Working Temperature: | -30~40℃ | ||
| Highlight: | 5700K Stadium Floodlights,140lm/W Stadium Floodlights,18W Stadium Lighting Floodlighting |
||
| No |
parameter
|
Unit | Value | ||
| 1 | Input Voltage | V | AC200～240 | ||
| 2 | Frequency | Hz | 50/60 | ||
| 3 | Rated Power |
Ordinary lamp |
w | 30 | |
Emergency lamp |
18/25/30 | ||||
| 4 | Power efficiency | Ordinary lamp | / | ＞90% | |
| Emergency lamp | ＞75% | ||||
| 5 | Power factor | / | ≥0.9 | ||
| 6 | Color temperature | K | 3000～5000 | ||
| 7 |
Rated luminous flux
|
lm |
According to the contract
|
||
| 9 |
Installation angle
|
° | -50～50 | ||
| 10 |
Maximum projected area subject to wind
|
m2 | Ordinary lamp | 0.021 | |
| Emergency lamp | 0.032 | ||||
| 11 | IP rating | / | IP65 | ||
| 12 | Electric Safety Class | / | CLASS I | ||
| 13 | Torque applied to a bolt or screw | N.m | 17 | ||
| 14 |
Protecting mask
|
/ |
Tempered glass
|
||
| 15 |
Ambient temperature
|
℃ | -30℃～40℃ | ||
| 16 | Dimension | Ordinary lamp | mm | 269×251×85 | |
| Emergency lamp | 269×251×124 | ||||
| 17 | Whole light weight | Ordinary lamp | Kg | 2.15 | |
| Emergency lamp | 2.35 | ||||
| 18 | Carton Size | Ordinary lamp | mm | 594×280×280 | |
| Emergency lamp | 594×360×280 | ||||
1.1 Product Features
GY290FGII series lamps are green and environment-friendly lamps manufactured by our company in accordance with national standards.
1.1.1 The power consumption of GY290FGII series lamps is one-fifth of that of traditional street lamps, and the power saving reaches 50%-70%.
1.1.2 The service life can reach 50,000 hours.
1.1.3 Does not contain ultraviolet and infrared rays, no radiation, stable gloss, and color difference not affected by age.
1.1.4 It does not contain harmful elements such as lead and mercury, and is green and environmentally friendly.
1.1.5 The modular design of multiple light sources and the use of high-transmittance PC lenses make the illumination range of the lamps wider and the illumination more uniform.
1.1.6 The radiator adopts aluminum die-casting molding process, the structure of the lamp is novel, and the design of the cooling teeth increases the heat dissipation area of the lamp, effectively prolonging the service life of the lamp
1.1.7 The protective cover is made of tempered cloth glass, the surface is evenly stressed, firm and reliable, easy to transport and clean with high-pressure water gun.
1.1.8 Reasonable sealing structure design makes the protection level of the lamp reach IP65.
1.1.9 The structure of the lamp is simple and reasonable, which is convenient for installation and maintenance.
Product structure and material:
290TGII series LED lights are composed of: 1. Glass frame 2. Tempered glass 3. Lens 4. Aluminum substrate 5. Light source 6. Mounting bracket 7. Power supply 8. Heat sink 9. Back cover (only for emergency lights) and hardware, Seals and other accessories.
Scope of application
GY290FGII series are suitable for factories, gymnasiums, docks, tunnels, billboards, buildings, lawn and gardening design and other places that require light projection and floodlight.
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Shipment
Seaport: Tianjin, Shanghai or Shenzhen
Production time:
The prepare time for item for samples is 7-10 days
The production time for normal order is 10-20 days
Others:
All the items will be test before shipment.
All the goods are sent from China for now.
All the order will be shipped by DHL, TNT, FedEx, or By sea, by air etc.
Estimated Time of arrival is 5-10 days by express, 7-10 days by air or 10-60 days by sea.
Company Profile
Aina-4 Technologies (Shanghai) Co., Ltd. is a private limited company registered in Shanghai, China. It specializes in the R&D, design, manufacture, and marketing of light emitting sources and lighting fixtures. It is an enterprise formed by four (4) pioneer lighting companies, putting their resources together to produce products and services that create sustainability not only for the environment, but also for the economies and societies that the company grows with.
FAQ
Q: How to find us?
A: WhatsApp /Skype/ Viber: +86 15989493560 or WeChat: 15989493560
Q: Are you factory?
A: Yes, Our factory is Aina lighting.
Q: How can I get the sample to check your quality?
A: After price confirmation, you can require for samples to check. The samples fee you paid will be return to you when there is formal orders step by step.
Q: How can I get your price?
A: We will send you quotation within 24 hours after getting your inquiry. If you need price urgent, you can find us any time by WhatsApp or WeChat or Viber
Q: What is your delivery time
A: For samples, normally will take around 5 days. For Normal order will be around 10-15 days
Q: What about the trade terms?
A: We accept EXW, FOB Shenzhen or Shanghai, DDU or DDP. You can choose the way which is the most convenient or cost effective for you.
Q: Can you add our logo on the products?
A: Yes, we can offer service of adding customers’ logo.
Q: Why Choose us?
A: We have three factories in different places focusing one different type of lights. We can offer more lighting choices for you.
We have different sales office, can offer you more Awesome services.
